ZONATO COMPACT LINE POLISHER


Additional Photos (Click to view Larger)




For Immediate Answers Contact:

Tony Cornacchione

(704) 841-2001 ext. 432
TCorn@exfactory.com





If not available, try his/her backup:
Torry Hiddema at ext ...371


EXF #:   SN-300014
Brand/Model:   ZONATO COMPACT
Machine Type:   LINE POLISHER
Year of Mfg.:   2024
Condition:   Brand New w/Warranty
Elect./Voltage:   230/460 V, 60 Cy, 3 Ph.
Appr. Repl. Cost:    94,500
Price:   $  91,200    USD (Convert)
Financing:    1,823/Mo.
Description:
ZONATO COMPACT Automatic Straight Edge Polishing Machine

The COMPACT Automatic belt edge polishing machine is manufactured with high quality materials. Easily fabricate marble, granite and agglomerate, to create and polish pencil round profiles, flat edges and flat edge plus bevels.

Specifications

  •  Thickness of work: 20 - 100 mm  (0.78" - 4")
  •  Minimum working width: 120 mm (4.75")
  •  Minimum length of work: 400 mm  (15.75")
  • Speed conveyor belt: 0 - 4500 mm/min (0 - 177")
  •  Belt width: 600 mm (23.5")
  • Polishing wheels diameter: 130 mm (5")

    Equipped with:
  • PLC Control with touch-screen
  • (7) Polishing units
  • (2) Upper beveling units
  • Lower bevel unit
  • Main covers in stainless steel
  • Electronic programmer for exit/entry spindles
  • Rugged electro-welded frame
  • Belt shifting surface covered in stainless steel
  • Belt with guides
  • Automatic spindle working cycle and pneumatic pressure rollers
  • Belt speed control
  • Manual bar for large-sized slabs support
  • Water collecting tank with conveyed outlets



Region: NORTHEAST (Click for Regional Map)
Special Note:
Comment: High quality and easy to use suitable for any stone fabrication field.
*Dimensions: 158" L x 67" W x 70" H
*Weight: 7,800 Lbs
Written By: Dale Granger
*Dimensions & Weight data are based on 3rd party information and could be incorrect; please verify & confirm if accurate dimensions & weight are required.
